FEATURESInterface1x Gigabit Ethernet PortButtonResetPower Supply• 802.3at PoE (Power Adapter included)• 48V Passive PoE• 12V/1.2A DCPower Consumption• EU: 13.3 W (For PoE); 11.8 W (for DC)• US: 14.7 W (For PoE); 12.6 W (for DC)
Weight
372g
Dimensions
( W x D x H )6.3 x 6.3 x 1.5 in (160 x 160 x 38.5 mm)Antenna Type• 2.4 GHz: 2x 3 dBi• 5 GHz: 3× 5 dBi (one auxiliary antenna included)Mounting• Ceiling /Wall Mounting (Kits included)• Junction Box MountingWIRELESS FEATURESCoverage140㎡(1500 ft²)***Concurrent Clients250+**
Wireless
Standards IEEE802.11 a/b/g/n/ac/axFrequency2.4 GHz and 5 GHzSignal Rate• 5 GHz: 2402 Mbps*• 2.4 GHz: 574 Mbps
Wireless
Functions• Seamless Roaming• Mesh• Beamforming• MU-MIMO• OFDMA‡• HE160‡• Band Steering• Load Balance• Airtime Fairness• RADIUS Accounting•
Wireless
Schedule• Static IP/Dynamic IP• Rate Limit: Based on SSID/Client• Multiple SSIDs: 16(8 on each band)• Enable/Disable
Wireless
Radio• Enable/Disable SSID Broadcast• Guest
Network
• Transmit Power Control: Adjust Transmit Power on dBm• QoS (WMM)
Wireless
Security• Captive Portal Authentication• Access Control• Maximum Number of MAC Filter: 4,000•
Wireless
Isolation Between Clients• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise• 802.1X Support• VLANTransmission Power• CE:<20 dBm(2.4 GHz, EIRP)<23 dBm(5 GHz, Band1 & Band2, EIRP)<27 dBm(5 GHz, Band3, EIRP)• FCC:<24 dBm (2.4 GHz)<25 dBm (5 GHz)MANAGEMENTNTPYesCentralized ManagementYesAPP supportFesta AppCloud AccessFree cloudLED ON/OFF ControlYesSNMPv1, v2c, v3System Logging Local/RemoteSyslogYesSSHYesZero-Touch ProvisioningYesOTHERSCertificationCE, FCC, RoHS, ICPackage Contents• Festa F65• Power Adapter• Ceiling/Wall Mounting Kit• Installation GuideSystem RequirementsMicrosoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, LinuxEnvironment• Operating Temperature: 0–40 (32–104 )•
Storage
Temperature: -40–70 (-40–158 )• Operating Humidity: 10–90% RH non-condensing•
Storage
Humidity: 5–90% RH non-condensing
