#1: Insulation Material – PE#2: Insulation dimension nominal – 1.0 mm + 0.1#3: Number colour (Strip Marking) -1. White/Blue & Blue2. White/Orange & Orange3. White/Green & Green4. White/Brown & BrownMECHANICAL CHARECTERISTICS:#4:
Storage
Temperature range -20 C to +75 C#5: Max. recommended pulling tension – 110 N#6: Min bend radius (install) – 8 x OD#7: Outer jacket tensile strength – > 9 Mpa#8: After aging Elongation – > 50% of Unaging#9: After aging tensile strength – > 70% of Unaging#10: Nom. Mutual capacitance – < 5.6 nF/100m (@1kHz)#11: Pair to ground capacitance Unbalance – < 1600 pF/km#12: Nominal velocity of propogation – 72%#13: Max. delay skew – 25 ns/100m#14: Max. conductor DC resistance – 95 /km (@ 20 C)#15: Max. conductor resistance unbalance – 2% (@20 C)#16: Min. Insulation resistance – 5000M-km#17: Max. operating Voltage – 300 V
