SpecificationsStandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3atLED indicatorsOne Link/Act LED indicator for each portOne PoE-MAX LED indicator for each deviceOne Power LED indicator for each deviceInterfaces8 * 10/100/1000 Mbps Base-T Ethernet ports (Data/Power)1 * 10/100/1000 Mbps Base-T Ethernet port (Data)1 * 100/1000 Mbps Base-X SFP portLightning protectionPort: 6kVPower: 6kVForwarding modeStore-and-forwardSwitching capability20GbpsPacket forwarding rate14.9MppsMAC address table16KPoE Power SupplyIEEE 802.3af/at standards PoE power supply on ports 1-8Voltage of cores 1, 2, 4, 5 is +, and cores 3, 6, 7, 8 is -Input voltage100-240V~ 50/60Hz
Dimensions
177.5 mm x 104 mm x 26 mm(L*W*H)Power ConsumptionTotal power consumption: <102 WMaximum PoE output: 92 WThree-Mode ToggleThree-mode toggle through one DIP switch:1. Standard: Default mode. In this mode, all ports can communicate with each other.2. VLAN: In this mode, ports 1 - 8 are isolated from each other,but all of them can communicate with port 9 and SFP1. This mode helps isolate DHCP broadcast and reduce broadcast storm.3. Extend: In this mode, ports 1 - 8 decrease to 10 Mbps in negotiation rate,but transmit up to 250 m in distance. All ports can communicate with each other.Operating environmentOperating temperature: 0°C - 45℃
Storage
temperature:-40°C - 70°COperating humidity:(10% - 90%)RH, non-condensing
Storage
humidity:(5% - 90%)RH, non-condensingCertificatesCCC、FCC、CE、RoHS
