Specifications
Model
CS-HB8 (4MP)CameraImage Sensor1/3” 4-Megapixel Progressive Scan SMOS SensorMinimum Illumination0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR (Data is obtained from EZVIZ laboratories)Shutter SpeedSelf-adaptive shutterLens4mm @ F1.6 Viewing angle: 100°(Diagonal), 83°(Horizontal), 44°(Vertical)PT AnglePan:340°, Tilt: 65°Day & NightIR-Cut filter with auto-switchingDNR3D DNRNight VisionUp to 49 ft / 15 mVideo & AudioMax.
Resolution
2560 × 1440Frame Rate15fps. Self-Adaptive during
Network
TransmissionVideo CompressionH.265 / H.264Video Bit RateUltra-HD; HD; Standard. Adaptive Bit Rate.Audio Bit RateSelf-AdaptiveMax. Bitrate2 Mbps
Network
Wi-Fi StandardIEEE802.11b, 802.11g, 802.11nFrequency Range2.4 GHz ~ 2.4835 GHzChannel Bandwidth Supports20 MHzSecurity64 /128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSKTransmission Rate11b11Mbps, 11g: 54Mbps, 11n: 150MbpsWi-Fi PairingAP pairingProtocolEZVIZ cloud proprietary protocolInterface ProtocolEZVIZ cloud proprietary protocolMinimum
Network
Requirement4MbpsFunctionDetectionSmart Human Motion DetectionTwo-way TalkSupportsGeneral FunctionAnti-Flicker, Heart Beat, Password Protection, Watermark
Storage
Local
Storage
Build-In 32GB eMMC
Storage
Cloud
Storage
Supports EZVIZ CloudPlay storage (Subscription required)GeneralOperating Conditions-20 °C to 50 °C (-4 °F to 122 °F ), humidity 95% or less (Non-condensing)IP GradeWeatherproof DesignPower ConsumptionMax.10W
Product Dimensions
183 × 116 × 166 mm (7.20 × 4.57 × 6.52 inch)Packaging
Dimensions
216 × 145 × 203 mm (8.50 × 5.71 × 7.99 inch)
Weight
Net:803 g (28.32 oz) With package: 1060 g (37.39 oz)
Battery
Battery
Capacity
10400 mAhPower SupplyDC 5V / 2A
In the box
In the box
- HB8 2K⁺ Camera- Drilling Template- USB Cable- Screw Kit- Quick Installation Guide- Regulatory Information- Quick Start GuideCertifications:Certifications:CE/FCC/WEEE/ROHS/REACH/UL
